Fractal Audio Firmware Update Thread

GTR37 said:
Have fun see you next week

forum.fractalaudio.com

Blocks Library UPDATED FOR 2023

Here's my updated and revised blocks library for FW23b. Edit - UPDATED FOR OCTOBER 2023. BLOCKS - https://tinyurl.com/2ct6t67f
forum.fractalaudio.com forum.fractalaudio.com
Click to expand...
Thanks buddy! One final question - will that still work with FM9 even though it was created for AxeFxIII v20? (I can just give it a try and see, but I won’t be able to until this evening, so thought I’d ask).

Fireproof said:
Thanks buddy! One final question - will that still work with FM9 even though it was created for AxeFxIII v20? (I can just give it a try and see, but I won’t be able to until this evening, so thought I’d ask).
Click to expand...
It works for any
Remember these are just individual blocks NOT presets
So if you have a delay block in your preset you just drag it and replace it with Leon’s delay block

FM3 Firmware Version 6.00 is now available for download:
https://www.fractalaudio.com/downloads/firmware-presets/fm3/6p0/fm3_dsp_rel_6p00.zip

FM3-Edit version 1.05.12 is required for this firmware.
https://forum.fractalaudio.com/threads/fm3-edit-1-05-12.189688/
NOTE: You must perform a "Refresh After New Firmware" in FM3-Edit to sync with this new firmware

RELEASE NOTES:

NEW AND IMPROVED FEATURES​

  • Optimizations to reduce CPU. This will vary depending on blocks used and settings.
  • Added Klone Chiron model to the Drive block.
  • Added Griddle Cake model based on Crowther Hot Cake to the Drive block. The “XLF” switch on the pedal can be replicated by turning the Bass Response knob fully CW.
  • Added the following new Amp models:
    • PVH 6160 Block Crunch
    • Diamante Fire based on a Diamond Del Fuego
    • Brit Studio 20 Amp model based on a Marshall SV20H
    • Plexi 50W 6CA7 Jumped
  • New “Cygnus X-2” amp modeling:
    • Improved Amp block output transformer algorithm. New algorithm more accurately models B-H curve resulting in a clearer low end. New algorithm now also accounts for effect of speaker impedance on transformer response.
    • Improved power tube modeling. This yields better dynamics, improved low frequency accuracy and more accurate interaction with output transformer.
    • Improved cathode follower algorithm. Provides more accurate “cleanup” when volume is rolled off.
    • Improved triode algorithm more accurately models plate bypass capacitors.
    • Many amp models have been updated as a result of the aforementioned improvements.
    • Various other improvements.
  • Improved modeling accuracy for following Amp models:
    • Plexi 50W Jumped
    • Plexi 100W Jumped
    • Brit JM45 Jumped
    • 1987X Jumped
    • 1959SLP Jumped
    • Plexi 100W 1970
    • Deluxe Tweed Jumped
    • Two Stone J35 and J35 PAB
    • Fox ODS and ODS Deep
    • Nuclear Tone
    • All Solo 88, 99 and 100 models
    • All Bogfish models
    • All Spawn Q-Rod models
    • All Spawn Nitrous models
    • All Vibrato Verb models
    • All Deluxe Verb models
    • All Double Verb models
    • All Brit 800 models
    • All Brit JVM models
    • All Friedman BE/HBE V2 and V3
    • Friedman Small Box
    • Cornfed M50
  • Drive block improvements. Drive block now incorporates the “Chase Transform Technique” for converting analog networks to equivalent digital filters. This improves accuracy in the high frequency region.
  • New “Block Mixer” algorithm results in faster/quieter scene and channel changes.
  • New Speaker Drive algorithm in Amp block. This new algorithm more accurately models the frequency dependent distortion of guitar loudspeakers. The default value (upon resetting the block) is 2.0 which gives roughly 1 dB of compression. Setting the value to 0.0 defeats the speaker drive modeling. Higher values give a smoother and more focused sound, rounding off the “sharp edges” and yielding greater compression.
  • Added Speaker Thump to Amp block. This models the dynamic, nonlinear behavior of a guitar speaker. A value of 5.0 roughly corresponds to an amp running into a speaker rated at the same power as the amplifier, i.e., a 100W amplifier running into a 100W speaker. The reset value is a conservative 2.5 which represents, i.e., a 50W amp running into a 100W speaker. Note that the majority of the response is in the subsonic region and the effect is primarily tactile. Existing presets are not affected and the value will be zero.
  • Improved Amp block output transformer modeling. This requires updated Transformer LF/HF values for the amp models. Existing presets are automatically updated to the new values upon recall.
  • Changed “Drive” to “Gain” for Amp block preamp gain as this is more consistent with naming in real amps.
  • Added “Overdrive Volume” parameter to Dumble-type amp models (ODS-100, Two Stone, etc.). This is sometimes labeled “Ratio” or “Lead Master”. As the Master Volume on these amps often has a bright capacitor the Overdrive Volume control allows setting the Master Volume higher to counteract the bright cap and then lowering the power amp drive with the Volume.
  • Added “Plate Suppressor Diodes” parameter. This value is set automatically when the amp model is chosen but the user can override the default setting. Most amps do not have suppressor diodes but some do (e.g., Trainwreck Express). These diodes (also called “snubber” or “flyback” diodes) prevent undershoot on the power tube plates due to inductive kick and reduce upper harmonics thereby reducing “fizz”.
  • Improved speaker impedance curve fitting algorithm. This results in more accurate and more “colorful” modeling as the previous algorithm tended to damp box resonances somewhat. All the speaker impedance curves have been updated using the new routine.
  • Added speaker impedance curves:
    • 4x12 Lerxst Omega
    • 1x12 Deluxe Oxford
    • 4x12 Hipower Pete T
    • 4x12 Hipower Lindsey B
    • 4x12 USA Semi-Open
    • 2x12 Dizzy RV
    • 4x12 London Town Tall
    • G12T-75
    • 2x12 Class-A Greenback
    • 2x12 Two Stone 1265
  • Added cross feedback parameters to Quad Parallel type in Multitap Delay block.
  • Increased the range of the Level parameters in Multitap Delay to -100% to +100%.
  • SPDIF output level will no longer be dependent on the volume knob.

FC FEATURES​

  • Added new Setlists/Songs feature, which can be used with the onboard switches and/or an FC Controller to access presets and scenes in custom order during live performance. A new Setup menu area provides full access from the front panel, with a corresponding new area of FM3-Edit which offering import/export and more. For additional details, please see the Setlists & Songs Mini-Manual, located at: https://www.fractalaudio.com/sss-manual

FIXES​

  • Fixed wrong coupling capacitor value in 1959SLP Treble, 1959SLP Jumped and 1987x Treble amp models.
  • Fixed wrong resistor value in tone stack of Solo 88 Rhythm and Lead models. Probably not audible though.
  • Fixed low frequency behavior of Recto2 models due to loss of precision.
  • Fixed wrong treble pot taper in CA3+ models.
  • Fixed wrong capacitor value in Friedman HBE V1 Fat model.
  • Fixed wrong resistor value in AC-20 12AX7 models.
  • Fixed wrong Depth knob taper in Archean models.
  • Fixed scale not being set when first attaching a modifier to a LOG parameter.
  • Fixed Bypass grayed out on Reverb EQ page.
  • FC: Layout Link will no longer unduly trigger when exiting the Tuner.
  • FC: Preset: Select in Bank switches now stop flashing when the preset is changed by any means other than an FC footswitch (editor, front panel, etc.)
  • FC: Preset: Select in Bank switches now flash consistently when used with Bank: Select switches.
  • FC: Preset: Toggle in Bank now consistently and correctly loads "Primary" preset after changing the bank.
  • FC: Effect: Channel functions will now work correctly when Effect is set to Controllers

Fireproof said:
FM3 Firmware Version 6.00 is now available for download:
https://www.fractalaudio.com/downloads/firmware-presets/fm3/6p0/fm3_dsp_rel_6p00.zip

FM3-Edit version 1.05.12 is required for this firmware.
https://forum.fractalaudio.com/threads/fm3-edit-1-05-12.189688/
NOTE: You must perform a "Refresh After New Firmware" in FM3-Edit to sync with this new firmware

RELEASE NOTES:

NEW AND IMPROVED FEATURES​

  • Optimizations to reduce CPU. This will vary depending on blocks used and settings.
  • Added Klone Chiron model to the Drive block.
  • Added Griddle Cake model based on Crowther Hot Cake to the Drive block. The “XLF” switch on the pedal can be replicated by turning the Bass Response knob fully CW.
  • Added the following new Amp models:
    • PVH 6160 Block Crunch
    • Diamante Fire based on a Diamond Del Fuego
    • Brit Studio 20 Amp model based on a Marshall SV20H
    • Plexi 50W 6CA7 Jumped
  • New “Cygnus X-2” amp modeling:
    • Improved Amp block output transformer algorithm. New algorithm more accurately models B-H curve resulting in a clearer low end. New algorithm now also accounts for effect of speaker impedance on transformer response.
    • Improved power tube modeling. This yields better dynamics, improved low frequency accuracy and more accurate interaction with output transformer.
    • Improved cathode follower algorithm. Provides more accurate “cleanup” when volume is rolled off.
    • Improved triode algorithm more accurately models plate bypass capacitors.
    • Many amp models have been updated as a result of the aforementioned improvements.
    • Various other improvements.
  • Improved modeling accuracy for following Amp models:
    • Plexi 50W Jumped
    • Plexi 100W Jumped
    • Brit JM45 Jumped
    • 1987X Jumped
    • 1959SLP Jumped
    • Plexi 100W 1970
    • Deluxe Tweed Jumped
    • Two Stone J35 and J35 PAB
    • Fox ODS and ODS Deep
    • Nuclear Tone
    • All Solo 88, 99 and 100 models
    • All Bogfish models
    • All Spawn Q-Rod models
    • All Spawn Nitrous models
    • All Vibrato Verb models
    • All Deluxe Verb models
    • All Double Verb models
    • All Brit 800 models
    • All Brit JVM models
    • All Friedman BE/HBE V2 and V3
    • Friedman Small Box
    • Cornfed M50
  • Drive block improvements. Drive block now incorporates the “Chase Transform Technique” for converting analog networks to equivalent digital filters. This improves accuracy in the high frequency region.
  • New “Block Mixer” algorithm results in faster/quieter scene and channel changes.
  • New Speaker Drive algorithm in Amp block. This new algorithm more accurately models the frequency dependent distortion of guitar loudspeakers. The default value (upon resetting the block) is 2.0 which gives roughly 1 dB of compression. Setting the value to 0.0 defeats the speaker drive modeling. Higher values give a smoother and more focused sound, rounding off the “sharp edges” and yielding greater compression.
  • Added Speaker Thump to Amp block. This models the dynamic, nonlinear behavior of a guitar speaker. A value of 5.0 roughly corresponds to an amp running into a speaker rated at the same power as the amplifier, i.e., a 100W amplifier running into a 100W speaker. The reset value is a conservative 2.5 which represents, i.e., a 50W amp running into a 100W speaker. Note that the majority of the response is in the subsonic region and the effect is primarily tactile. Existing presets are not affected and the value will be zero.
  • Improved Amp block output transformer modeling. This requires updated Transformer LF/HF values for the amp models. Existing presets are automatically updated to the new values upon recall.
  • Changed “Drive” to “Gain” for Amp block preamp gain as this is more consistent with naming in real amps.
  • Added “Overdrive Volume” parameter to Dumble-type amp models (ODS-100, Two Stone, etc.). This is sometimes labeled “Ratio” or “Lead Master”. As the Master Volume on these amps often has a bright capacitor the Overdrive Volume control allows setting the Master Volume higher to counteract the bright cap and then lowering the power amp drive with the Volume.
  • Added “Plate Suppressor Diodes” parameter. This value is set automatically when the amp model is chosen but the user can override the default setting. Most amps do not have suppressor diodes but some do (e.g., Trainwreck Express). These diodes (also called “snubber” or “flyback” diodes) prevent undershoot on the power tube plates due to inductive kick and reduce upper harmonics thereby reducing “fizz”.
  • Improved speaker impedance curve fitting algorithm. This results in more accurate and more “colorful” modeling as the previous algorithm tended to damp box resonances somewhat. All the speaker impedance curves have been updated using the new routine.
  • Added speaker impedance curves:
    • 4x12 Lerxst Omega
    • 1x12 Deluxe Oxford
    • 4x12 Hipower Pete T
    • 4x12 Hipower Lindsey B
    • 4x12 USA Semi-Open
    • 2x12 Dizzy RV
    • 4x12 London Town Tall
    • G12T-75
    • 2x12 Class-A Greenback
    • 2x12 Two Stone 1265
  • Added cross feedback parameters to Quad Parallel type in Multitap Delay block.
  • Increased the range of the Level parameters in Multitap Delay to -100% to +100%.
  • SPDIF output level will no longer be dependent on the volume knob.

FC FEATURES​

  • Added new Setlists/Songs feature, which can be used with the onboard switches and/or an FC Controller to access presets and scenes in custom order during live performance. A new Setup menu area provides full access from the front panel, with a corresponding new area of FM3-Edit which offering import/export and more. For additional details, please see the Setlists & Songs Mini-Manual, located at: https://www.fractalaudio.com/sss-manual

FIXES​

  • Fixed wrong coupling capacitor value in 1959SLP Treble, 1959SLP Jumped and 1987x Treble amp models.
  • Fixed wrong resistor value in tone stack of Solo 88 Rhythm and Lead models. Probably not audible though.
  • Fixed low frequency behavior of Recto2 models due to loss of precision.
  • Fixed wrong treble pot taper in CA3+ models.
  • Fixed wrong capacitor value in Friedman HBE V1 Fat model.
  • Fixed wrong resistor value in AC-20 12AX7 models.
  • Fixed wrong Depth knob taper in Archean models.
  • Fixed scale not being set when first attaching a modifier to a LOG parameter.
  • Fixed Bypass grayed out on Reverb EQ page.
  • FC: Layout Link will no longer unduly trigger when exiting the Tuner.
  • FC: Preset: Select in Bank switches now stop flashing when the preset is changed by any means other than an FC footswitch (editor, front panel, etc.)
  • FC: Preset: Select in Bank switches now flash consistently when used with Bank: Select switches.
  • FC: Preset: Toggle in Bank now consistently and correctly loads "Primary" preset after changing the bank.
  • FC: Effect: Channel functions will now work correctly when Effect is set to Controllers
Click to expand...
Must have spent the time on this instead of pressing the Zazzle report button.

Fireproof said:
FM3 Firmware Version 6.00 is now available for download:
https://www.fractalaudio.com/downloads/firmware-presets/fm3/6p0/fm3_dsp_rel_6p00.zip

FM3-Edit version 1.05.12 is required for this firmware.
https://forum.fractalaudio.com/threads/fm3-edit-1-05-12.189688/
NOTE: You must perform a "Refresh After New Firmware" in FM3-Edit to sync with this new firmware

RELEASE NOTES:

NEW AND IMPROVED FEATURES​

  • Optimizations to reduce CPU. This will vary depending on blocks used and settings.
  • Added Klone Chiron model to the Drive block.
  • Added Griddle Cake model based on Crowther Hot Cake to the Drive block. The “XLF” switch on the pedal can be replicated by turning the Bass Response knob fully CW.
  • Added the following new Amp models:
    • PVH 6160 Block Crunch
    • Diamante Fire based on a Diamond Del Fuego
    • Brit Studio 20 Amp model based on a Marshall SV20H
    • Plexi 50W 6CA7 Jumped
  • New “Cygnus X-2” amp modeling:
    • Improved Amp block output transformer algorithm. New algorithm more accurately models B-H curve resulting in a clearer low end. New algorithm now also accounts for effect of speaker impedance on transformer response.
    • Improved power tube modeling. This yields better dynamics, improved low frequency accuracy and more accurate interaction with output transformer.
    • Improved cathode follower algorithm. Provides more accurate “cleanup” when volume is rolled off.
    • Improved triode algorithm more accurately models plate bypass capacitors.
    • Many amp models have been updated as a result of the aforementioned improvements.
    • Various other improvements.
  • Improved modeling accuracy for following Amp models:
    • Plexi 50W Jumped
    • Plexi 100W Jumped
    • Brit JM45 Jumped
    • 1987X Jumped
    • 1959SLP Jumped
    • Plexi 100W 1970
    • Deluxe Tweed Jumped
    • Two Stone J35 and J35 PAB
    • Fox ODS and ODS Deep
    • Nuclear Tone
    • All Solo 88, 99 and 100 models
    • All Bogfish models
    • All Spawn Q-Rod models
    • All Spawn Nitrous models
    • All Vibrato Verb models
    • All Deluxe Verb models
    • All Double Verb models
    • All Brit 800 models
    • All Brit JVM models
    • All Friedman BE/HBE V2 and V3
    • Friedman Small Box
    • Cornfed M50
  • Drive block improvements. Drive block now incorporates the “Chase Transform Technique” for converting analog networks to equivalent digital filters. This improves accuracy in the high frequency region.
  • New “Block Mixer” algorithm results in faster/quieter scene and channel changes.
  • New Speaker Drive algorithm in Amp block. This new algorithm more accurately models the frequency dependent distortion of guitar loudspeakers. The default value (upon resetting the block) is 2.0 which gives roughly 1 dB of compression. Setting the value to 0.0 defeats the speaker drive modeling. Higher values give a smoother and more focused sound, rounding off the “sharp edges” and yielding greater compression.
  • Added Speaker Thump to Amp block. This models the dynamic, nonlinear behavior of a guitar speaker. A value of 5.0 roughly corresponds to an amp running into a speaker rated at the same power as the amplifier, i.e., a 100W amplifier running into a 100W speaker. The reset value is a conservative 2.5 which represents, i.e., a 50W amp running into a 100W speaker. Note that the majority of the response is in the subsonic region and the effect is primarily tactile. Existing presets are not affected and the value will be zero.
  • Improved Amp block output transformer modeling. This requires updated Transformer LF/HF values for the amp models. Existing presets are automatically updated to the new values upon recall.
  • Changed “Drive” to “Gain” for Amp block preamp gain as this is more consistent with naming in real amps.
  • Added “Overdrive Volume” parameter to Dumble-type amp models (ODS-100, Two Stone, etc.). This is sometimes labeled “Ratio” or “Lead Master”. As the Master Volume on these amps often has a bright capacitor the Overdrive Volume control allows setting the Master Volume higher to counteract the bright cap and then lowering the power amp drive with the Volume.
  • Added “Plate Suppressor Diodes” parameter. This value is set automatically when the amp model is chosen but the user can override the default setting. Most amps do not have suppressor diodes but some do (e.g., Trainwreck Express). These diodes (also called “snubber” or “flyback” diodes) prevent undershoot on the power tube plates due to inductive kick and reduce upper harmonics thereby reducing “fizz”.
  • Improved speaker impedance curve fitting algorithm. This results in more accurate and more “colorful” modeling as the previous algorithm tended to damp box resonances somewhat. All the speaker impedance curves have been updated using the new routine.
  • Added speaker impedance curves:
    • 4x12 Lerxst Omega
    • 1x12 Deluxe Oxford
    • 4x12 Hipower Pete T
    • 4x12 Hipower Lindsey B
    • 4x12 USA Semi-Open
    • 2x12 Dizzy RV
    • 4x12 London Town Tall
    • G12T-75
    • 2x12 Class-A Greenback
    • 2x12 Two Stone 1265
  • Added cross feedback parameters to Quad Parallel type in Multitap Delay block.
  • Increased the range of the Level parameters in Multitap Delay to -100% to +100%.
  • SPDIF output level will no longer be dependent on the volume knob.

FC FEATURES​

  • Added new Setlists/Songs feature, which can be used with the onboard switches and/or an FC Controller to access presets and scenes in custom order during live performance. A new Setup menu area provides full access from the front panel, with a corresponding new area of FM3-Edit which offering import/export and more. For additional details, please see the Setlists & Songs Mini-Manual, located at: https://www.fractalaudio.com/sss-manual

FIXES​

  • Fixed wrong coupling capacitor value in 1959SLP Treble, 1959SLP Jumped and 1987x Treble amp models.
  • Fixed wrong resistor value in tone stack of Solo 88 Rhythm and Lead models. Probably not audible though.
  • Fixed low frequency behavior of Recto2 models due to loss of precision.
  • Fixed wrong treble pot taper in CA3+ models.
  • Fixed wrong capacitor value in Friedman HBE V1 Fat model.
  • Fixed wrong resistor value in AC-20 12AX7 models.
  • Fixed wrong Depth knob taper in Archean models.
  • Fixed scale not being set when first attaching a modifier to a LOG parameter.
  • Fixed Bypass grayed out on Reverb EQ page.
  • FC: Layout Link will no longer unduly trigger when exiting the Tuner.
  • FC: Preset: Select in Bank switches now stop flashing when the preset is changed by any means other than an FC footswitch (editor, front panel, etc.)
  • FC: Preset: Select in Bank switches now flash consistently when used with Bank: Select switches.
  • FC: Preset: Toggle in Bank now consistently and correctly loads "Primary" preset after changing the bank.
  • FC: Effect: Channel functions will now work correctly when Effect is set to Controllers
Click to expand...
Enjoy FM3 owners
It is an Amazing update IMO
As I have said many times prior
Probably one off the most noticeable and gratifying to my ears
Especially with the low end attack

You Mean this ---> Drive block now incorporates the “Chase Transform Technique
Isn't that like some sort of Flux Capacitor thingy ? :LOL:

forum.fractalaudio.com

Gift of Tone #10: COOPER CARTER

Be sure to watch the video on the downloads page for details on the presets. https://www.fractalaudio.com/gift-of-tone/#10 NOTE: Friday Dec 9, 7PM EST: A new zip file was uploaded to circumvent an issue with Axe-Edit setting modifier scale incorrectly to 0% when importing presets originally...
forum.fractalaudio.com forum.fractalaudio.com

Cooper Carter today

Mongillo19 said:
forum.fractalaudio.com

Gift of Tone #10: COOPER CARTER

Be sure to watch the video on the downloads page for details on the presets. https://www.fractalaudio.com/gift-of-tone/#10 NOTE: Friday Dec 9, 7PM EST: A new zip file was uploaded to circumvent an issue with Axe-Edit setting modifier scale incorrectly to 0% when importing presets originally...
forum.fractalaudio.com forum.fractalaudio.com

Cooper Carter today
Click to expand...
That’s cool 10 more to go likely
I think I guessed a few of them this week the Austin Buddy , Cooper
And Andy Wood
Mikko and Moke I missed
Although the Moke Magic pitch block is nuts , these guys amaze me

I love seeing Gilmour and EJ in the same shot. Stick Vai in the middle and you got this-


You must log in or register to reply here.

Similar threads

L
Headrush Firmware
Replies
4
Views
2K
likitlikeyoulikeit
L
S
New modeler: Analysis paralysis (book)
6 7 8
Replies
141
Views
9K
Sascha Franck
Sascha Franck
M
Tone X 1.5 Update
2 3 4
Replies
67
Views
7K
MirrorProfiles
MirrorProfiles
Lele
Helix - Bogner 101B Blue ch. - German Xtra Blue - Settings
Replies
4
Views
780
Foxmeister
Foxmeister
N
UPDATE: NAM Plugin version 0.7.6 is released
Replies
1
Views
1K
LeftyLoungeLizard
LeftyLoungeLizard
Back
Top
